Wilson AG Pro 4G +70dB Amplifier Kit - 461104

Product subtitle:

3G & 4G LTE Signal Booster Kit All US Carriers, for Home & Office (10,000 sq.ft)


Boosts Talk, Text, and 4G LTE Data; For Buildings up to 7,500 sq ft; Up to +70 dB Gain



New Item Title:

weBoost Connect 4G-X - 471104

New Item Link:




Product Label:



Wilson Electronics

Cable Type:



2 Years

White Arrow
Price Match Guarantee


100% Satisfaction

  • 30-day money-back guarantee.

100% Service & Support:

  • Free shipping on all items! 2 year warranty.

100% Security:

  • Google Trusted Store verified by PayPal, BBB, and Authorize.net.

DISCONTINUED. See the new model of this product.
weBoost Connect 4G-X
Cell Phone Booster Kit - 471104

Wilson 461104 AG Pro 4G (Formerly called AG Pro Quint) Amplifier Kit boosts talk, text, internet, 2G, 3G, AWS, and 4G/LTE for most US carriers: AT&T, Verizon, T-Mobile, Sprint, US Cellular, etc. (except Clearwire and Nextel) for home or office, large area (10,000 sq ft), up to 70dB gain. This is the NEW & REDESIGNED FCC and IC approved 2014 model, complete DIY kit. This upgraded model has a new automatic adjustment feature that takes away the need for manual gain adjustment.

Dropped calls, lost internet connection, poor voice quality (fish tank voice), low bars, slow downloads, limited range and reception... these are common and frustrating cell phone reception problems. When everything you do doesn't improve your situation, trust in a Wilson Electronics cell phone signal booster, an industry leader in wireless communications with over 40 years of reputable engineering and assembly.

The Wilson AG Pro 4G is your solution, because it significantly amplifies signals and enhances performance, resulting in faster data speeds, reliable service, stronger signals, wider coverage, fewer no-service dead zones and interruptions. It's smooth sailing (or calling, texting, emailing...) from here on out.


  • This model is designed to increase cellular data (talk, text, internet, 2G, 3G, AWS, and 4G/LTE) in a large area up to 10,000 sq ft and 70dB gain


  • Supports providers that transmit in the following frequencies: 698-746 MHz, 746-787 MHz, 824-894 MHz, 1850-1995 MHz, 1710-1755/2110-2155MHz
  • AT&T, Verizon, Sprint, T-Mobile, US Cellular, Leap Wireless, C Spire, etc.
  • Please contact us (email: sales@wilsonamplifiers.com, call: 1-800-568-2723, live chat) for further help about compatibility with your service. We'd be glad to provide you the best service.

 Wilson AG Pro 4G Booster Complete Kit includes:

  • Wilson 460004 5-Band Cellular Repeater/Amplifier
  • Wilson 311135 Indoor Wall Panel Antenna
  • Wilson 314411 Outdoor Yagi Directional  Antenna
  • Wilson 952360 + 952375 60'+75' Black LMR400 Ultra Low Loss Coaxial Cable
  • Wilson A/C Power Adapter
  • Wilson 461104 AG Pro 4G Installation Manual
Product Features:
  • Boosts Talk, Text, Internet, 2G, 3G, AWS, 4G/LTE data for American US cellular carriers (except iDEN & WiMax)
  • Supports CDMA, GSM, EVDO, LTE, HSPA+ and WCDMA technologies
  • Reduces dropped calls, increases data speed, extends signal range, faster video downloads
  • Everything included, easy to install, complete do-it-yourself kit
  • Allows for multiple users and cellular devices (smartphones, tablets, etc) to be used simultaneously
  • Boosted signal for a large area up to 10,000 sq ft+ coverage area
  • The AG Pro 4G’s has a new self-adjusting design greatly simplifies installation. It automatically senses and adjusts gain on each of the frequency bands, which allows greater flexibility in the placement of antennas, and minimizes installation time.
  • Stronger signal to and from cell tower
  • Compact design, less than three pounds
  • Cell site protection technology
  • Wilson Electronics best and most affordable five-band home signal amplifier/ booster for large area
  • FCC-approved
  • UPC: 811815022206
  • Made in the USA
  • New and improved version, replaces the Wilson 803670 AG Pro Quint
  • Looking for a more affordable solution? Check out the Wilson DT4G Kit.

Download the Installation Manual here

This is a CONSUMER device.

BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider.

  • You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person.
  • You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider.
  • WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.
  • Please note, the four largest carriers - AT&T, T-Mobile, Verizon and Sprint - and more than 90 regional carriers have given blanket consent for use of all boosters certified to the new FCC standards.

There are no fees to register your device. Wilson Amplifiers provides a free service to help you along the way. Please check out our blog for more information.

  1. Did not work for our application ratings and reviews

    Posted by Michael Nelson on 6th Jan 2015

    We purchased a Wilson DB Pro for our 48X60 steel barn and it worked great. No bars to full bars 4G. BUT, we also ordered a Wilson AG 4G Pro for our home, and we could not get it stagged or configured to work. The antenna's were 50ft apart and facing away from each other, but always had green and red flashing lights and no better signal. Since this model does not have gain adjsutment there was nothing we could do, but return the unit. It probably works great for some applications but not for us. We plan to order another Wilson DB Pro Unit for our home, since we have had such good luck with that unit. Nice to have the 30 day money back.

  2. outstanding product ratings and reviews

    Posted by Robert Edgell Dawson Springs, Kentucky on 18th Nov 2014

    I am outside the 4G service area for broadband internet and could only get 1 bar for cell telephone if I would stand in one spot in my house. After installing the Wilson system, I can now get 2 bars and sometimes 3 for 4G service and can now get 3 to 4 bars anywhere in my house and outside for the telephone. My next door neighbor has also improved his cell signal if he is outside.

  3. Great Product ratings and reviews

    Posted by Jose Villanueva / NJ on 5th Nov 2014

    We have two buildings and depending on where you were at, had shotty signal. Purchased one to test and worked great so purchased another for the other building.

    Great product and an easy install. Met all of our needs.

  4. Solved our cell phone signal problem ratings and reviews

    Posted by Frank Condurelis - Houston on 10th Oct 2014

    This is a great- easy to install product. If you have low signal in your building this is worth the investment

  5. Satisfied Canadian (Rogers) User ratings and reviews

    Posted by Andrew Canada on 15th Sep 2014

    -Using product in a 2,000sq/ft town home in Canada with the Rogers network. I used to get about 1-2 bars of Edge (-110 to -120db's) on the second floor only, no signal on main or basement.

    -Setup was easy (took about 30 minutes) I installed the outdoor antenna in attic where I managed to pick up 2-3 bars of LTE and indoor antenna in basement. Now I get 4 bars of LTE (-80 to -90db) in basement, 3 bars of LTE on main floor (-90 to -110db) and 2-3 bars on second floor (around -110 to -120db). I am considering buying another indoor antenna for the second floor so I get better signal upstairs but honestly it works great even with 2 bars of LTE.

    -I am a bit surprised that I'm not getting 3-4 bars everywhere since it is advertised to work in large 10,000sq/ft areas. They may have tested the range in one big room.. floors and walls do degrade the signal.

    -Unit gets hot which could lead to premature failure in electronics. (Product does have 2 year warranty).

    -Unit is built with good quality metal, connectors, generous length of coax however the wires on the antennas seem fragile/small compared to the black coax wire provided.

    Overall I still give this product a 5 star because it has been working great for me, good quality and I haven't had a single problem.

  6. Does the job ! ratings and reviews

    Posted by Joe F Waynesburg, PA on 22nd Aug 2014

    Easily installed and adjusted. Provides great coverage. It boosted signals from zero 4G to full signal 4G in our control room at this facility.

    Highly recommended.

  7. Wilson 461104 AG Pro Quint Amplifier ratings and reviews

    Posted by Ted / Roswell, GA on 11th Aug 2014

    Installed the kit this weekend and am very happy so far. Found address for closest tower and then calculated azimuth to use compass to point the antenna directly to it.

    Went from 1 bar to 4 bars inside my house.

  8. Haven't installed the system yet ratings and reviews

    Posted by Andre/Stafford, VA on 10th Jun 2014

    I received the system as promised, was packaged properly and everything that was supposed to be there, was. I have not installed it yet but in two weeks when I return and install it I will post an operational review.
    Shipping was great!
