500 Ft 1/2 inch Plenum Cable Spool - No Connector
No more annoying dropped calls, poor call quality & slow Internet!
500 ft. spool of half inch, low-loss coaxial cable for wireless applications,white Plenum cable.
- ETL Certified CMP (UL 444) Rated
- Low passive intermodulation and high efficiency signal transfer
- For indoor plenum use (dropped ceilings and raised floors)
- Meets all code requirements for installation in plenum air handling spaces
Plenum cable is mandated to be installed in any "air handling" space by the National Electric Code. Knowing when a space requires Plenum Cable is very important. One of the easiest ways to do this is to look into the ceiling. If you see a duct going back to the Air Hauler then this means you have a Closed Air System, however if there isn't a duct running back to the Air Hauler then you have an Open-Air System, and this is a Plenum Space and will require Plenum Cable.
Goodbye, no-signal frustrations.
What's included in the kit?
500ft 1/2" Plenum Cable SpoolItem # 952003
Product Specifications
| Loss @ 30 MHz 100 ft / 30 m |
0.40 dB |
| Loss @ 150 MHz 100 ft / 30 m |
0.90 dB |
| Loss @ 450 MHz 100 ft / 30 m |
1.59 dB |
| Loss @ 824 MHz 100 ft / 30 m |
2.19 dB |
| Loss @ 1700 MHz 100 ft / 30 m |
3.25 dB |
| Loss @ 2400 MHz 100 ft / 30 m |
3.93 dB |
| Loss @ 3000 MHz 100 ft / 30 m |
4.44 dB |
| Dielectric Insulation |
Polyethylene |
| Center Conductor Material |
Copper Clad Aluminum |
| Center Conductor Diameter |
Corrugated Aluminum Tube |
| Operating Temperature (°F / °C) |
-4 to167 / -20 to 75 |
| Weight (lbs. / kg) |
120/55 |
Wilson 1/2" Plenum Cable Spec Sheet(PDF)
Installation Instructions: Videos
Part 1 of 6:
Where to Install Your Booster.
Part 2 of 6:
Installing the Outside Antenna.
Part 3 of 6:
Running Cable into Your Home.
Part 4 of 6:
Installing the Inside Antenna.
Part 5 of 6:
Installing the Booster.
Part 6 of 6:
Troubleshooting & Checking Your Signal.
INSTALLATION GUIDES (PDF)
If you have questions or require assistance, please call our customer and tech support at 1-800-568-2723 or email at sales@WilsonAmplifiers.com. We will be happy to assist you in every step of the way.
