Wilson Pole Mount Panel Antenna (50 Ohm) - 314453 - Front
Wilson Pole Mount Panel Antenna (50 Ohm) - 314453

Wilson Pole Mount Panel Antenna (50 Ohm) - 314453

Wilson Pole Mount Panel Antenna (50 Ohm) - 314453 - Front
  • Outdoor directional 4G Antenna
  • Easy installation
  • Includes pole mount bracket
  • 50-Ohm variants
  • Up to +10.6 dB gain

Options Available:

Dealing with poor cell signal?
Call our experts for a FREE consultation
Pay With Pay With Affirm
Payment Options
Shipping Guarantee
Friendly USA based
customer support.
Shipping Guarantee
FREE standard shipping
on all orders*.
Money-Back Guarantee
Up to 30 day
Money-back guarantee.
Shipping Guarantee
Up to 1 year
manufacturer's warranty.

Read Featured Reviews From Actual Customers Read All Reviews

About Wilson Pole Mount Panel Antenna (50 Ohm)

Outdoor cellular panel antennas are directional antennas for receiving cellular signal. They are less directional than Yagi antennas but far more than omnidirectional antennas. They are best placed on walls, as opposed to roofs, though they can be placed anywhere with the included pole mount.

The important bits to note are the ohmage and bandwidths the antennas cover. All our panel antennas are wideband, which means they cover all North American carriers.

Be sure to purchase panel antennas with the correct ohmage for your system.

Feel free to call us at 1-800-568-2723 for help choosing or for free advice.

Technical Specifications

FREQUENCY 700-800 MHz;
824-894 MHz;
880-960 MHz;
1710-1880 MHz;
1850-1990 MHz;
2110-2170 MHz
RADIATION Directional
IMPEDANCE 50 / 75 Ohms
MAX POWER 50 Watts
MOUNTS Mounts on pipe 0.5-1.5 inches in diameter
CONNECTORS N-Female / F-Female
